Chapter 5 internal_combustion_engine • 1. INTERNAL COMBUSTION ENGINE • INTRODUCTION What is IC Engine?  An internal combustion engine is a thermal system (power plant) that converts heat obtained from chemical energy sources (gasoline, natural gas) into mechanical work.

Where are IC Engines Used?  IC engines are used as the propulsion systems for land transport vehicles such as automobiles (cars, etc.), marine vehicles (boats, etc.) and small airplanes.  IC engines are also used in portable electrical generators and as prime mover in grass cutting machine, etc. 2 • 3 INTRODUCTION Basic Components of IC Engines • Cylinder, piston, inlet valve and exhaust valve. • Piston moves from the top dead center (TDC) to the bottom dead center (BDC).

Download

Download

• Clearance volume, Vc is a spacing between the top of the piston and the valve’s heads when the piston is at the end of the delivery stroke. • Swept volume or displacement volume, Vs is the volume between TDC and BDC. • ENGINE CLASSIFICATION 4 Reciprocating internal combustion (IC) engines are classified into two general categories, depending on how the combustion process in the cylinder is initiated, i.e.: a) Spark-ignition (SI) engines; b) Compression-ignition (CI) engines.

Description of SI Engines • Run on liquid fuel such as gasoline or petrol, which is mixed with air. • The air-fuel mixture enters the cylinder and is compressed to a highest pressure and temperature. • ENGINE CLASSIFICATION 5 Description of SI Engines • A spark from a spark-plug ignites the combustible air- fuel mixture. /get-the-worlds-1-speech-recognition-software-for-mac/.

• It burns and combustion gases are produced. • The high pressure of the gases pushes the piston downwards, producing a power stroke of the piston. • The crankshaft transforms the reciprocating motion into rotational motion (rpm), which is carried by gears and drive shaft systems to the wheels, causing the vehicle to move. • ENGINE CLASSIFICATION 6 Description of CI Engines Run on diesel liquid fuel. • The fresh atmospheric air enters the cylinder in which it is compressed to about 1/22 of its original volume, causing its temperature to raise to about 540 oC or higher. • Diesel fuel is then injected into the compressed air. • The heat of compression of the air causes the diesel to burn.

• ENGINE CLASSIFICATION 7 Description of CI Engines • Thus producing high temperature combustion gases. • The combustion gases pushes the piston downward during the power stroke of the piston. • As in the SI engines, the reciprocating motion is transformed into rotational motion. IN BOTH ENGINES, THE COMBUSTION GASES ARE EVENTUALLY EXHAUSTED OUT OF THE CYLINDER SO THAT FRESH-AIR MIXTURE CAN BE INDUCED INTO THE CYLINDER TO CONTINUE THE THERMODYNAMICS CYCLES – therefore working on an open cycle is the characteristics of all internal combustion engines since the working fluid does not undergo a complete thermodynamic cycle. • PERFORMANCE CRITERIA 8 Compression Ratio, rv Compression ratio = Maximum volume Minimum volume Note: compression ratio is volume ratio and it is not a pressure ratio.

Inlet valve (air) • PERFORMANCE CRITERIA 9 Mean Effective Pressure, MEP • Mean effective pressure (MEP) is a conceptual/fictitious pressure. • If it acted on the piston during the entire power stroke, would produce the same amount of net work as that produced during the actual cycle. • PERFORMANCE CRITERIA 10 Mean Effective Pressure • PERFORMANCE CRITERIA 11 Mean Effective Pressure • CLASSIFICATION BY CYCLES 12 Reciprocating internal combustion engines operate either on two- stroke or four-stroke cycle. Four-stroke Cycle • Most automotive engines operate on a 4-stroke cycle. • Every fourth piston stroke is the power stroke.
